RV-5 Setup
3-7
ASSIGNING AUDIO and VIDEO INPUT CONNECTORS
The RV-5 has eight configurable inputs, each of which can be assigned to its ten digital audio, eight analog audio, the built-in tuner, the phono
input, two HDMI video, four composite video, four S-Video or three component video input connectors.
The table below indicates the INPUT SETUP menu parameters that
can be used to assign audio and video input connectors.
Note:
The digital audio input connectors are compatible with PCM (44.1, 48,
88.2 and 96kHz), Dolby Digital and DTS (-ES) sources. The digital audio
input connectors are also compatible with MPEG or MP3 sources through
the DOCK input.
DIG AUDIO COAXIAL-1 to 4, HDMI-1, HDMI-2,
OPTICAL-1 to 4, NONE
Opens the DIG AUDIO menu, which is used to assign a digital audio
input connector for the selected input. The RV-5 has ten configurable
inputs, each of which can be assigned to any of its ten digital audio
input connectors.
Please note the following:
• When no digital audio input connector is assigned, the RV-5 will
automatically set the MAIN ADV menu INPUT SELECT
parameter to ANALOG (see page 3-15).
• A digital audio input connector must be assigned when no
analog audio input connector is assigned. Refer to the next page
for information about assigning an analog audio input
connector.
DVD DIG AUDIO
COAXIAL-2
COAXIAL-3
COAXIAL-4
OPTICAL-1
OPTICAL-2
OPTICAL-3
OPTICAL-4
INPUTS
SPEAKERS
I/O CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGER
TUNER SETUP
MAIN MENU
AUDIO CONTROLS
VIDEO CONTROLS
SETUP
DISPLAY SETUP
8-CH INPUT:
SURROUND CONFIG
DOLBY SURR SETUP
SPEAKER/EQ SETUP
POWER ON SETTINGS
5.1+A/D
SETUP
INPUT SETUP
HDMI 2
NONE
HDMI 1
HDMI 2
COAXIAL-1
INPUT SETUP: INPUT SETUP 1
INPUT:
DIG AUDIO:
ANLG AUDIO:
DIG/ANLG AUTO:
A/D SAMPLE RATE:
DVD 1
ON
HDMI 2
NONE
MODE FAMILY:
MODE:
48kHz
STEREO
2-CHANNEL
NAME: ________
Parameter Possible Settings
DIG AUDIO COAX-1 to 4, HDMI-1, HDMI-2, OPTICAL-1 to 4,
NONE
ANLG AUDIO ANALOG-1 to 6, 7.1 CHANNEL, TUNER, NONE
VIDEO IN COMPONENT-1 to 3, COMPOSITE-1 to 4,
HDMI-1, HDMI-2, S-VIDEO-1 to 4
INPUTSETUP
DIG AUDIO
To Next Page
