REAR-PANEL OVERVIEW (continued)
CAUTION! Never make or break connections to the RV-5
unless the RV-5 and all associated components are
powered off.
1 MICROPHONE INPUT CONNECTOR
Provides a microphone input for speaker calibration.
2 ANALOG AUDIO INPUT CONNECTORS
Provides analog audio inputs. Eight connectors labeled Front L/R,
Center, LFE, Side L/R and Rear L/R are available.
3 MAIN ZONE AUDIO OUTPUT CONNECTORS
Provides analog audio outputs in the Main Zone. Six stereo analog
audio input connectors labeled 1 to 6 are available.
4 DIGITAL AUDIO INPUT CONNECTORS
Provides digital audio input in the Main Zone. Four S/PDIF coaxial
and four S/PDIF optical (Toslink) input connectors are available.
Connectors are compatible with PCM (44.1, 48, 88.2 and 96kHz),
Dolby Digital, and DTS(-ES) sources. Connectors are not compatible
with MPEG (MP3) sources.
5 USB CONNECTOR PORT
Provides a USB port to connect to a compatible computer running
Windows® 2000, Windows® XP, or higher with the latest service
packs installed to listen to audio from the computer through the RV-
5. The USB connector port is a “Mini B” connector and can also be
used to connect a compatible computer to the RV-5 for firmware
upgrades, when available. See page xxxx for more information on
playback of computer audio.
6 TRIGGER OUTPUT CONNECTORS
Provide 12V DC output to control connected components. Two
trigger output connectors are available on a removable terminal
block. The PWR connector (the power trigger output connector) is
not configurable. It is activated when the RV-5 is powered on, and
deactivated when the RV-5 is powered off from the rear panel or by
putting the RV-5 into standby. The trigger output connector
(labeled 1) can be configured for remote or program operation. See
“Trigger Setup” on page 3-70 for more information.
7 RS-232 CONNECTOR
The RS-232 serial connector provides serial control and is used to
perform configuration downloads and flash memory software
upgrades.
8 VIDEO INPUT CONNECTORS
Provides the Main Zone video inputs. Four composite video
connectors labeled 1 to 4 and four S-Video connectors labeled 1 to
4 are available.
