Lexmark C3224 User Manual

6 Open a web browser, and then go to https://lexmark.cloud-connect.co.
7 Click Next, and then accept the Terms of Use.
8 Enter the authorization code, and then click Connect.
9 Log in to your cloud service provider account.
10 Grant permissions.
Note: To complete the authorization process, open the profile within 72 hours.
Managing bookmarks
Creating bookmarks
Use bookmarks to print frequently accessed documents that are stored in servers or on the web.
1 Open a web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address on the printer home screen. The IP address appears as four sets of
numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the web page correctly.
2 Click Bookmarks > Add Bookmark, and then type a bookmark name.
3 Select an Address protocol type, and then do one of the following:
• For HTTP and HTTPS, type the URL that you want to bookmark.
• For HTTPS, make sure to use the host name instead of the IP address. For example, type
myWebsite.com/sample.pdf instead of typing 123.123.123.123/sample.pdf. Make sure that
the host name also matches the Common Name (CN) value in the server certificate. For more information
on obtaining the CN value in the server certificate, see the help information for your web browser.
• For FTP, type the FTP address. For example, myServer/myDirectory. Enter the FTP port. Port 21 is
the default port for sending commands.
• For SMB, type the network folder address. For example, myServer/myShare/myFile.pdf. Type the
network domain name.
• If necessary, select the Authentication type for FTP and SMB.
To limit access to the bookmark, enter a PIN.
Note: The application supports the following file types: PDF, JPEG, TIFF, and HTML-based web pages.
Other
file
types such as DOCX and XLXS are supported in some printer models.
4 Click Save.
Creating folders
1 Open a web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address on the printer home screen. The IP address appears as four sets of
numbers separated by periods, such as 123.123.123.123.
Set up, install, and configure 21

Lexmark C3224 Specifications

General

Print Technology	Laser
Print Speed	Up to 24 ppm
Memory	256 MB
Input Capacity	250 sheets
Output Capacity	100 sheets
Duplex Printing	Manual
Supported Operating Systems	Windows, Mac OS, Linux
Print Resolution	600 x 600 dpi
Monthly Duty Cycle	30, 000 pages
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Weight	30.9 lbs
