Linking trays
1 From the control panel, navigate to:
Settings > Paper > Tray Conguration
For non-touch-screen printer models, press
to navigate through the settings.
2 Select a paper source.
3 Set the same paper size and paper type for the trays that you are linking.
4 From the control panel, navigate to:
Settings > Device > Maintenance > Config Menu > Tray Conguration
5 Set Tray Linking to Automatic.
Note: To unlink trays, make sure that no trays have the same paper size and paper type settings.
Warning—Potential Damage: The temperature of the fuser varies according to the specified paper type. To
avoid printing issues, match the paper type setting in the printer with the paper loaded in the tray.
Installing and updating software, drivers, and firmware
Installing the printer software
Notes:
The print driver is included in the software installer package.
For Macintosh computers with macOS version 10.7 or later, you do not need to install the driver to print
on an AirPrint-certified printer.
1 Obtain a copy of the software installer package.
From the software CD that came with your printer.
Go to http://support.lexmark.com, and then select your printer and operating system.
2 Run the installer, and then follow the instructions on the computer screen.
Updating firmware
Some applications require a minimum device firmware level to operate correctly.
For more information on updating the device firmware, contact your Lexmark representative.
1 Open a web browser, and then type the printer IP address in the address field.
Notes:
View the printer IP address on the printer home screen. The IP address appears as four sets of
numbers separated by periods, such as 123.123.123.123.
If you are using a proxy server, then temporarily disable it to load the web page correctly.
2 Click Settings > Device > Update Firmware.
Set up, install, and configure 26

Table of Contents

Other manuals for Lexmark C3326

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark C3326 and is the answer not in the manual?

Lexmark C3326 Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Duplex printing modeAuto
Print speed (black, normal quality, A4/US Letter)26 ppm
Duplex print speed (black, normal quality, A4/US Letter)13 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle50000 pages per month
Recommended duty cycle600 - 2500 pages per month
Number of print cartridges-
Page description languagesPCL 5, PCL 6, PCLm, PostScript 3
Average cartridge yield (CMY)2500 pages
Average cartridge yield (black)3000 pages
DisplayLCD
CertificationENERGY STAR, DE-UZ 205, ICES-003 Class B, US FDA/CDRH, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62311, EN 55022(Class B), EN 55024, EN 61000, EN 61000, UL), EFTA (CE), KCC, CCC, CECP, CEL, RCM DoC, UL-AR, KC mark, UL GS mark, UCRF
Product colorBlack, White
Display number of lines2 lines
Power consumption (ready)17 W
Power consumption (printing)395 W
Energy Star Typical Electricity Consumption (TEC)0.31 kWh/week
Paper input typePaper tray
Total input capacity251 sheets
Total output capacity100 sheets
Total number of input trays2
Server operating systems supportedSUSE Linux Enterprise Server 10, SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12, Windows Server 2003, Windows Server 2003 x64
Windows operating systems supportedWindows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 Enterprise x64
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Hagaki card, Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Multi-purpose tray media typesEnvelopes, Executive, Labels, Legal, Letter, Plain paper
Maximum ISO A-series paper sizeA4
Operating altitude0 - 3048 m
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth556 mm
Package width332 mm
Package height519 mm
Package weight19100 g
Internal memory512 MB
Processor frequency1000 MHz
Sound pressure level (printing)52 dB
Sound pressure level (duplex printing)51 dB
Cables includedAC
Included cartridge capacity (CMY)500 pages
Included cartridge capacity (black)750 pages
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Security algorithmsHTTPS, IPSec, SNMP, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB connectorUSB Type-B
Sustainability certificatesEPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth394.1 mm
Width411.2 mm
Height243.7 mm
Weight16100 g
