Lexmark C746 Connection Guide

Installing the printer locally (Windows)
Note: If the Software and Documentation CD does not support the operating system, then use the Add Printer Wizard.
Updates for the printer software may be available on the Lexmark Web site at www.lexmark.com.
What is local printing?
Local printing is printing to a locally attached printer (a printer that is connected directly to your computer with a USB cable).
When setting up this type of printer, you should install the printer software before connecting the USB cable. For more
information, see the setup documentation that came with the printer.
The Software and Documentation CD can be used to install the necessary printer software on most Windows operating systems.
Installing the printer using the Add Printer Wizard (Windows)
Note: For the list of supported Windows operating systems, see “Supported operating systems” on page 1.
1 Close all open software programs.
2 Insert the Software and Documentation CD.
3 Close the installation software.
4 Add the printer:
a Click , or click Start and then click Run.
b In the Start Search or Run field, type control printers.
c Press Enter, or click OK.
d From the Printer Tasks area, click Add a printer.
5 When prompted, select to install a local printer, and then click Have Disk.
6 Specify the location of the printer software.
Note: The path should be similar to D:\Drivers\Print\GDI\, where D is the letter of your CD or DVD drive.
7 Click OK.
Installing the printers on a network (Windows)
What is network printing?
In Windows environments, network printers can be configured for direct printing or shared printing. Both network printing
methods require the installation of printer software and the creation of a network port.
Printing method Example
IP printing
• Printer is connected directly to the network using a network cable, such as an Ethernet cable.
• Printer software is typically installed on each network computer.
Connection Guide
Page 2 of 5

Lexmark C746 Specifications

General

Color	Yes
Print technology	Laser
Resolution color	2400 x 600 DPI
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	9 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	85000 pages per month
Recommended duty cycle	1500 - 9200 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS
Paper input type	Paper tray
Total input capacity	650 sheets
Total output capacity	300 sheets
Maximum input capacity	4300 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 218 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies	-
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level (idle)	32 dB
Maximum internal memory	1536 MB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	48 dB
Display	LCD
Certification	CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class A, BSMI Class A, VCCI Class A, US FDA, FCC Class A, UL 60950-1, EN/IEC 60320-1, CE Class A, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class A, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class A, CCC Class A, CISPIR 22 Class A, MIC Mark, EK Mark
Product color	Black, White
Display diagonal	2.4 \
Power consumption (off)	6.8 W
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude	0 - 3048 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	553 mm
Package width	588 mm
Package height	545 mm
Package weight	29700 g

Weight and Dimensions

Depth	400 mm
Width	435 mm
Height	455 mm
