Lexmark CS410 Printing Guide

3 Squeeze the length guide tab, and then slide the guide to the correct position for the size of the paper being loaded.
1
2
Note: Use the size indicators on the bottom of the tray to help position the guide.
4 Squeeze and slide the width guide to the correct position for the size of the paper being loaded.
2
1
Note: Use the paper size indicators on the bottom of the tray to help position the guides.
5 Flex the sheets back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface.
Printing guide
Page 2 of 8

Lexmark CS410 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB, Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Monthly Duty Cycle	75, 000 pages
Maximum Memory	2304 MB
Duplex Printing	Yes
Mobile Printing	Yes
