Lexmark CS421dn - CS321 control panel badge cover

Assembly 1: 2-line control panel
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X2070 1 1 CS321 control panel
badge cover
“2‑line control panel badge cover
removal” on page 285
1 41X2127 1 1 SC2325 control panel
badge cover
“2‑line control panel badge cover
removal” on page 285
2 41X2044 1 1 2-line control panel bezel
“2‑line control panel bezel removal”
on page 287
3 41X2047 1 1 2-line control panel
assembly
“2‑line control panel assembly
removal” on page 290
4 41X2045 1 1 2-line control panel top
cover
“2‑line control panel top cover
removal” on page 291
5 41X2046 1 1 2-line control panel
ribbon cable
“2‑line control panel top cover
removal” on page 291
6 41X1305 1 1 2-line control panel base
cover
“Control panel base removal” on
page 284
