Lexmark CX923 User Manual

Object type Color conversion tables
RGB Image
RGB Text
RGB Graphics
• Vivid—Produces brighter, more saturated colors and may be
applied to all incoming color formats.
• sRGB Display—Produces an output that approximates the colors
shown on a computer monitor. Black toner usage is optimized for
printing photographs.
• Display‑True Black—Produces an output that approximates the
colors shown on a computer monitor. This setting uses only black
toner to create all levels of neutral gray.
• sRGB Vivid—Provides an increased color saturation for the sRGB
Display color correction. Black toner usage is optimized for
printing business graphics.
• O
CMYK Image
CMYK Text
CMYK Graphics
• US CMYK—Applies color correction to approximate the
Specifications
for Web
Oset
Publishing (SWOP) color output.
• Euro CMYK—Applies color correction to approximate Euroscale
color output.
• Vivid CMYK—Increases the color saturation of the US CMYK color
correction setting.
•
O
FAQ about color printing
What is RGB color?
RGB color is a method of describing colors by indicating the amount of red, green, or blue used to produce
a certain color. Red, green, and blue light can be added in various amounts to produce a large range of colors
observed in nature. Computer screens, scanners, and digital cameras use this method to display colors.
What is CMYK color?
CMYK color is a method of describing colors by indicating the amount of cyan, magenta, yellow, and black
used to reproduce a particular color. Cyan, magenta, yellow, and black inks or toners can be printed in various
amounts to produce a large range of colors observed in nature. Printing presses, inkjet printers, and color
laser printers create colors in this manner.
How is color specified in a document to be printed?
Software programs are used to specify and modify the document color using RGB or CMYK color
combinations. For more information, see the software program Help topics.
How does the printer know what color to print?
When printing a document, information describing the type and color of each object is sent to the printer and
is passed through color conversion tables. Color is translated into the appropriate amounts of cyan, magenta,
yellow, and black toner used to produce the color you want. The object information determines the application
of color conversion tables. For example, it is possible to apply one type of color conversion table to text while
applying a dierent color conversion table to photographic images.
Troubleshooting 256

Lexmark CX923 Specifications

General

Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Fax, Print, Scan
Country of origin	China
Maximum duty cycle	250000 pages per month
Recommended duty cycle	7000 - 50000 pages per month
Number of print cartridges	-
Control type	Touch
Product color	Black, Grey
Built-in display	Yes
Display diagonal	10 \
Market positioning	Business
Print technology	Laser
Resolution color	1200 x 1200 DPI
Maximum resolution	- DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.1 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
USB connector	USB Type-A / USB Type-B
Optional connectivity	Fiber, Near Field Communication (NFC), Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	5
Cabling technology	10/100/1000Base-T(X)
Security algorithms	IPSec, TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4
Supported network protocols (IPv6)	TCP/IP IPv6
Internal memory	2048 MB
Processor cores	4
Processor frequency	1200 MHz
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (standby)	29 dB
Sound pressure level (printing)	52 dB
Sound pressure level (scanning)	53 dB
Sound pressure level (duplex printing)	54 dB
Copier resize	25 - 400 %
Time to first copy (black, normal)	4.9 s
Time to first copy (color, normal)	5.8 s
Copy speed (black, normal quality, A4)	55 cpm
Power consumption (ready)	230 W
Power consumption (sleep)	2.78 W
Power consumption (copying)	1100 W
Power consumption (standby)	0.2 W
Power consumption (printing)	1075 W
Power consumption (scanning)	250 W
Energy Star Typical Electricity Consumption (TEC)	1.35 kWh/week
Scan to	E-mail, FTP, LDSS, PC, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPEG, JPG, TIFF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Operating altitude	0 - 2500 m
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	15 - 85 %
Faxing	Color faxing
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Package depth	911 mm
Package width	758 mm
Package height	1505 mm
Package weight	168000 g
Included cartridge capacity (CMY)	11500 pages
Included cartridge capacity (black)	18500 pages
Total input capacity	2150 sheets
Total output capacity	250 sheets
Maximum input capacity	5150 sheets
Paper tray 1 input capacity	500 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media weight	60 - 256 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Super Tabloid (media size), Universal
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 300 g/m²

Weight and Dimensions

Depth	792 mm
Width	615 mm
Height	1225 mm
Weight	134500 g
