Lexmark CX923 User Manual

CAUTION—POTENTIAL INJURY: Do not cut, twist, bind, crush, or place heavy objects on the power
cord. Do not subject the power cord to abrasion or stress. Do not pinch the power cord between objects
such as furniture and walls. If any of these things happen, a risk of fire or electrical shock results. Inspect
the power cord regularly for signs of such problems. Remove the power cord from the electrical outlet
before inspecting it.
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, make sure that all external
connections (such as Ethernet and telephone system connections) are properly installed in their marked
plug-in ports.
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, if you are accessing the controller
board or installing optional hardware or memory devices sometime after setting up the printer, then turn
the printer o, and unplug the power cord from the electrical outlet before continuing. If you have any
other devices attached to the printer, then turn them o as well, and unplug any cables going into the
printer.
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not use the fax feature during a
lightning storm.
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock when cleaning the exterior of the
printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before
proceeding.
CAUTION—POTENTIAL INJURY: If the printer weight is greater than 20 kg (44 lb), then it may require
two or more people to lift it safely.
CAUTION—POTENTIAL INJURY: When moving the printer, follow these guidelines to avoid personal
injury or printer damage:
• Make sure that all doors and trays are closed.
• Turn o the printer, and then unplug the power cord from the electrical outlet.
• Disconnect all cords and cables from the printer.
• If the printer has separate floor-standing optional trays or output options attached to it, then disconnect
them before moving the printer.
• If the printer has a caster base, then carefully roll it to the new location. Use caution when passing over
thresholds and breaks in
flooring.
• If the printer does not have a caster base but is configured with optional trays or output options, then remove
the output options and lift the printer
o
the trays. Do not try to lift the printer and any options at the same
time.
• Always use the handholds on the printer to lift it.
• Any cart used to move the printer must have a surface able to support the full footprint of the printer.
• Any cart used to move the hardware options must have a surface able to support the dimensions of the
options.
• Keep the printer in an upright position.
• Avoid severe jarring movements.
• Make sure that your fingers are not under the printer when you set it down.
• Make sure that there is adequate clearance around the printer.
CAUTION—TIPPING HAZARD: Installing one or more options on your printer or MFP may require a
caster base, furniture, or other feature to prevent instability causing possible injury. For more information
on supported configurations, see
www.lexmark.com/multifunctionprinters.
Safety information 8

Lexmark CX923 Specifications

General

Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Fax, Print, Scan
Country of origin	China
Maximum duty cycle	250000 pages per month
Recommended duty cycle	7000 - 50000 pages per month
Number of print cartridges	-
Control type	Touch
Product color	Black, Grey
Built-in display	Yes
Display diagonal	10 \
Market positioning	Business
Print technology	Laser
Resolution color	1200 x 1200 DPI
Maximum resolution	- DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.1 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
USB connector	USB Type-A / USB Type-B
Optional connectivity	Fiber, Near Field Communication (NFC), Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	5
Cabling technology	10/100/1000Base-T(X)
Security algorithms	IPSec, TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4
Supported network protocols (IPv6)	TCP/IP IPv6
Internal memory	2048 MB
Processor cores	4
Processor frequency	1200 MHz
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (standby)	29 dB
Sound pressure level (printing)	52 dB
Sound pressure level (scanning)	53 dB
Sound pressure level (duplex printing)	54 dB
Copier resize	25 - 400 %
Time to first copy (black, normal)	4.9 s
Time to first copy (color, normal)	5.8 s
Copy speed (black, normal quality, A4)	55 cpm
Power consumption (ready)	230 W
Power consumption (sleep)	2.78 W
Power consumption (copying)	1100 W
Power consumption (standby)	0.2 W
Power consumption (printing)	1075 W
Power consumption (scanning)	250 W
Energy Star Typical Electricity Consumption (TEC)	1.35 kWh/week
Scan to	E-mail, FTP, LDSS, PC, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPEG, JPG, TIFF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Operating altitude	0 - 2500 m
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	15 - 85 %
Faxing	Color faxing
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Package depth	911 mm
Package width	758 mm
Package height	1505 mm
Package weight	168000 g
Included cartridge capacity (CMY)	11500 pages
Included cartridge capacity (black)	18500 pages
Total input capacity	2150 sheets
Total output capacity	250 sheets
Maximum input capacity	5150 sheets
Paper tray 1 input capacity	500 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media weight	60 - 256 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Super Tabloid (media size), Universal
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 300 g/m²

Weight and Dimensions

Depth	792 mm
Width	615 mm
Height	1225 mm
Weight	134500 g
