Parts catalog
Legend
The following column headings are used in the parts catalog:
• Asm‑index—Identifies the item in the illustration
• P/N—Identifies the part number of a FRU
• Units/mach—Refers to the number of units in a printer
• Units/opt—Refers to the number of units in an option
• Units/FRU—Refers to the number of units in a FRU
• Description—A brief description of the part
The following abbreviations are used in the parts catalog:
• NS (not shown) in the Asm‑index column indicates that the part is procurable but is not shown in the
illustration.
• PP (parts packet) in the Description column indicates that the part is contained in a parts packet.
