Lexus 2013 IS250C User Manual

456
4-3. Do-it-yourself maintenance
9
E/G-B 60 A
FR CTRL-B, ETCS, ALT-S, A/F, TEL,
STR LOCK
10
ABS1 50 A VDIM
11
RH J/B-B 30 A FR DOOR RH, AM2
12
MAIN 30 A H-LP R LWR, H-LP L LWR
13
STARTER 30 A
Smart access system with push-button
start
14
LH J/B-B 30 A FR DOOR LH, SECURITY
15
P/I-B 60 A INJ, F/PMP, EFI
16
EPS 80 A Power steering
17
ALT 150 A
LH J/B-AM, E/G-AM, GLW PLG2,
HEATER, FAN1, FAN2, ABS2, RH
J/B-AM, GLW PLG1, RR R/B-AM
18
RR R/B-AM 80 A
DEFOG, PSB, ROOF RH, ROOF
LH, LGG RH, LGG LH, LGG LCK
RH, LGG LCK LH, P-TRAY MAIN,
P-TRAY SIDE
19
GLW PLG1 50 A PTC heater
20
RH J/B-AM 80 A
OBD, STOP SW, TI&TE, FR P/SEAT
RH, RAD NO.3, ECU-IG RH,
RH-IG, FR S/HTR RH, ACC, CIG,
PWR OUTLET, DOOR DL
21
ABS2 30 A VDIM
22
FAN2 40 A Electric cooling fans
23
FAN1 40 A Electric cooling fans
24
HEATER 50 A Air conditioning system
25
GLW PLG2 50 A PTC heater
Fuse Ampere Circuit
