464
4-3. Do-it-yourself maintenance
■ Trunk
Fuse Ampere Circuit
1
DEFOG 30 A Rear window defogger
2
ROOF RH 30 A Retractable hardtop
3
ROOF LH 30 A Retractable hardtop
4
LGG RH 30 A Retractable hardtop
5
LGG LH 30 A Retractable hardtop
6
LGG LCK RH 30 A Retractable hardtop
7
LGG LCK LH 30 A Retractable hardtop
8
P-TRAY MAIN 30 A Retractable hardtop
9
P-TRAY SIDE 7. 5 A Retractable hardtop
10
PSB 30 A Pre-collision seat belt
■ After a fuse is replaced
● If the lights do not turn on even after the fuse has been replaced, a bulb may
need replacement. (P. 4 68)
● If the replaced fuse blows again, have the vehicle inspected by your Lexus
dealer.
■ If there is an overload in the circuits
The fuses are designed to blow, protecting the wiring harness from damage.
To Next Page
