4-3. Do-it-yourself maintenance
4
Maintenance and care
10
CIG 15 A Cigarette lighter
11
PWR OUTLET 15 A Power outlet
12
FR DOOR RH 20 A
Power windows, outside rear view
mirrors
13
AM2 7.5 A Starting system
14
RH-IG 7.5 A
Seat belt pretensioner, intuitive park-
ing assist, automatic transmission, seat
heater and ventilator
15
FR S/HTR RH 15 A
Seat heaters and ventilators, air condi-
tioning system
16
ECU-IG RH 10 A
Power seats, headlights, front fog
lights, parking lights, license plate
lights, front side marker lights, wind-
shield washer, outside rear view mir-
rors, VDIM, air conditioning system,
pre-collision seat belt, electric tilt and
telescopic steering, power windows,
navigation system, vehicle stability
control, retractable hardtop, clock
Fuse Ampere Circuit
To Next Page
