Lexus CT200h - Page 563

563
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_U (OM76040U)
11
AMP NO.2 30 A Audio system
12
ETCS 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
13
IGCT 30 A PCU, IGCT NO.2, IGCT NO.3
14
DC/DC-S 5 A Inverter and converter
15
P CON MAIN 7.5 A
P position control system, P position
switch
16
AM2 7.5 A Power management system
17
ECU-B2 7.5 A
Smart access system with push-button
start
18
MAYDAY 10 A MAYDAY
19
ECU-B3 10 A Air conditioning system
20
TURN & HAZ 10 A Turn signal lights, emergency flashers
21
AMP NO.1 30 A Audio system
22
ABS MAIN NO.1 20 A Electronically controlled brake system
23
P/I 2 40 A
P position control system, horn, head-
lights (low beam), back-up lights
24
ABS MTR 1 30 A Electronically controlled brake system
25
ABS MTR 2 30 A Electronically controlled brake system
Fuse Ampere Circuit
