Lexus CT200h - Page 564

564
4-3. Do-it-yourself maintenance
CT200h_U (OM76040U)
26
H-LP HI MAIN 20 A H-LP RH HI, H-LP LH HI
27
DRL 7.5 A Daytime running light system
28
DOOR NO.2 25 A Power door lock system
29
P/I 1 60 A IG2, EFI MAIN, BATT FAN
30
EPS 60 A Electric power steering system
31
PCU 10 A Hybrid system
32
IGCT NO.2 10 A
Hybrid system, P position control sys-
tem, power management system
33
IGCT NO.3 10 A Cooling system
34
DOME 10 A
Luggage compartment light, over-
head module, interior lights, personal
lights, vanity lights, footwell lights
35
ECU-B 7.5 A
Smart access system with push-button
start, front passenger occupant classi-
fication system, gauges and meters,
outside rear view mirrors, air condi-
tioning system, driving position mem-
ory system, electric power steering
system, clock
36
H-LP LH HI 10 A Left-hand headlight (high beam)
37
H-LP RH HI 10 A Right-hand headlight (high beam)
Fuse Ampere Circuit
