Lexus CT200h - Page 565

565
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_U (OM76040U)
38
EFI NO. 2 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, exhaust system, key off pump
module, electric cooling fans
39
M-HTR 10 A Outside rear view mirror defoggers
40
SPARE 30 A Spare fuse
41
SPARE 10 A Spare fuse
42
SPARE 7.5 A Spare fuse
43
EFI MAIN 20 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, cooling system, EFI NO.2
44
BATT FAN 10 A Battery cooling fan
45
IG2 20 A
Hybrid system, multiport fuel injec-
tion system/sequential multiport fuel
injection system, MET, IGN, power
management system
Fuse Ampere Circuit
