4-3. Do-it-yourself maintenance
CT200h_U (OM76040U)
11
ECU-IG NO.1 10 A No circuit
12
S/ROOF 30 A Moon roof
13
DOOR RL 25 A Power windows
14
DOOR RR 25 A Power windows
15
D FR DOOR 25 A
Power windows, outside rear view
mirrors
16
P FR DOOR 25 A
Power windows, outside rear view
mirrors
17
STOP 10 A
Stop/tail lights, electronically con-
trolled brake system, pre-collision sys-
tem
18
RR FOG 7.5 A Stop/tail lights
19
FUEL OPEN 7.5 A Fuel filler door opener
20
OBD 7.5 A On-board diagnosis system
21
PWR SEAT 30 A Power seat
22
FR FOG 15 A Front fog lights
23
DBL LOCK 25 A No circuit
24
PSB 30 A Pre-collision seat belts
25
STRG HTR 10 A Heated steering wheel
26
DOOR NO.1 25 A Power door lock system
Fuse Ampere Circuit
To Next Page
