4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_U (OM76040U)
3
IGN 10 A
Electronically controlled brake sys-
tem, smart access system with push-
button start, multiport fuel injection
system/sequential multiport fuel injec-
tion system, stop/tail lights, SRS air-
bags
4
MET 7.5 A Gauges and meters
5
WIP 30 A Windshield wipers
6
RR WIP 20 A Rear window wiper and washer
7
WAS HE R 15 A Windshield washer
8
A/C 10 A Air conditioning system
9
GAUGE 10 A
Windshield wiper de-icer switch,
automatic headlight leveling system
10
ECU-IG NO.2 10 A
Windshield wipers, intuitive parking
assist, electronically controlled brake
system, navigation system, electric
power steering system, turn signal
lights, emergency flashers, yaw rate
and G sensor, headlight cleaner, out-
side rear view mirrors, driving mode
select switches, overhead module,
pre-collision seat belts, seat heater
switches, heated steering wheel
switch, tire pressure warning system,
dynamic radar cruise control
Fuse Ampere Circuit
To Next Page
