COMFORT ADJUSTMENT
124
16E406
"
1
Side and curtain shield airbag sensor assemblies
2
Airbag module for front passenger
(airbag and inflator)
3
Side airbag modules (airbag and inflator)
4
Curtain shield airbag modules (airbag and inflater)
5
Curtain shield airbag sensor assemblies
6
SRS warning light
7
Airbag module for driver (airbag and inflator)
8
Driver’s seat position sensor
9
Driver’s seat belt buckle switch
10 Front airbag sensors
11 Airbag sensor assembly
The SRS airbag system consists mainly of the above
components, and their locations are shown in the illustration.
The airbag sensor assembly consists of a safing sensor and
airbag sensor.
