ELECTRICAL COMPONENTS
340
No.
FUSE AMPERE CIRCUIT
45 AM1 5 Starting system
46 FOG 15 Front fog lights
47
SUN−
SHADE
15
Rear sunshade
48 GAUGE2 10
Auto anti−glare inside rear
view mirror, compass, back−up
lights, automatic light control
system, automatic headlight
leveling system, cruise control
system, seat belt reminder
lights
49 PANEL 10
Glove box light, console box
light, clock, outside
temperature gauge,
multi−information display,
instrument cluster lights,
instrument panel lights,
overdrive−off indicator light
50 TAIL 10
Tail lights, parking lights,
license plate lights
51 PWR NO.4 20
Rear passenger’s power
window (left side)
No. FUSE AMPERE CIRCUIT
52 PWR NO.2 20
Front passenger’s door lock
system, front passenger’s
power window
53 OBD 7.5 On−board diagnosis system
54
SEAT
HTR
20
Seat heaters
55 WASHER 15 Windshield washer
56
FAN
RLY
10
Electric cooling fans
57 STOP 15
Stop lights, high mounted stop-
light
58
FUEL
OPEN
5
Fuel filler door opener
59
DOOR
NO.2
25
Multiplex communication
system (power door lock
system, auto−door locking
system, wireless remote
control system)
60 AMP 25 Car audio system
61 PWR NO.3 20
Rear passenger’s power
window (right side)
