ELECTRICAL COMPONENTS
339
No.
FUSE AMPERE CIRCUIT
33 ECU−B 10
Multiplex communication
system (power door lock
system, security system,
auto−door locking system,
automatic light control system,
headlight delay off system, tail
light auto cut system,
illuminated entry system,
daytime running light system,
wireless remote control
system) air conditioning
system, electronic modulated
suspension, driving position
memory system
34 DOME 7.5
Ignition switch light, interior
light, personal lights, foot
lights, door courtesy lights,
trunk light, vanity lights, garage
door opener, clock, outside
temperature gauge,
multi−information display
35 CIG 15 Cigarette lighter
36
ECU−
ACC
5
Power rear view mirrors, clock,
multi−information display,
driving position memory
system
No. FUSE AMPERE CIRCUIT
37 RAD NO.2 10
Car audio system, navigation
system
38
POWER
POINT
15
Power outlet
39 RAD NO.1 20
Car audio system, navigation
system
40 GAUGE1 10
Gauges and meters, clock,
outside temperature gauge,
multi−information display, shift
lock system
41 ECU−IG 10
SRS airbag system, power
windows, anti−lock brake
system, electronic modulated
suspension, driving position
memory system
42 WIPER 25 Windshield wipers
43 HTR 10 Air conditioning system
44
MIR
HTR
10
Outside rear view mirror
heaters
