ELECTRICAL COMPONENTS
338
No.
FUSE AMPERE CIRCUIT
19 ABS NO.2 40
Anti−lock brake system,
vehicle skid control system,
traction control system, brake
assist system
20 MAIN 40
All components in “HEAD LH
LWR”, “HEAD RH LWR”, “HEAD
LH UPR”, “HEAD RH UPR” and
“DRL” fuses
21 ABS NO.3 40
Anti−lock brake system,
vehicle skid control system,
traction control system, brake
assist system
22 HTR 50 Air conditioning system
23 RDI 30 Electric cooling fan
24 SPARE 5 Spare fuse
25 SPARE 10 Spare fuse
26 ABS NO.1 60
All components in “RDI FAN”,
“ABS NO.2”, “ABS NO.3”,
“CDS”, “HTR (50 A)” and “ADJ
PDL” fuses and anti−lock brake
system, vehicle skid control
system, traction control
system, brake assist system
No. FUSE AMPERE CIRCUIT
27 ALT 120
All components in “DEF”, “PWR
NO.1”, “PWR NO.2”, “PWR
NO.3”, “PWR NO.4”, “STOP”,
“DOOR NO.2”, “OBD”, “PWR
SEAT”, “FUEL OPEN”, “FOG”,
“AMP”, “PANEL”, “TAIL”,
“AM1”, “CIG”, “POWER
POINT”, “RAD NO.2”,
“ECU−ACC”, “GAUGE1”,
“GAUGE2”, “ECU−IG”,
“WIPER”, “WASHER”, “HTR
(10 A)”, “SEAT HTR” and
“SUN−SHADE” fuses
28 SPARE 15 Spare fuse
29 A/C 10 Air conditioning system
30 DRL 5 Daytime running light system
31
HEAD RH
LWR
15
Right−hand headlight (low
beam)
32
HEAD LH
LWR
15
Left−hand headlight (low
beam) and front fog lights
