Lexus ES300 - Page 351

ELECTRICAL COMPONENTS
337
No.
FUSE AMPERE CIRCUIT
1 ABS NO.4 7.5
Anti−lock brake system,
vehicle skid control system,
traction control system, brake
assist system
2 A/F 25
Multiport fuel injection
system/sequential multiport
fuel injection system
3 DOOR1 25
Multiplex communication
system (power door lock
system, auto−door locking
system, wireless remote
control system)
4 TEL 5 No circuit
5 AM2 30
All components in “IGN” and
“IG2” fuses and starting system
6 EFI 20
Multiport fuel injection
system/sequential multiport
fuel injection system
7 ALT−S 5 Charging system
8
HEAD LH
UPR
10
Left−hand headlight (high
beam)
No. FUSE AMPERE CIRCUIT
9 ETCS 10
Multiport fuel injection
system/sequential multiport
fuel injection system
10 HORN 10 Horns
11 IGN 15 Starting system
12
HEAD RH
UPR
10
Right−hand headlight (high
beam)
13 HAZ 15 Emergency flashers
14 D.C.C 30
All components in “ECU−B”,
“RAD NO.1” and “DOME” fuses
15 IG2 10
Multiport fuel injection
system/sequential multiport
fuel injection system, SRS
airbag system, front seat belt
pretensioners, cruise control
system
16 ST 5 Starting system
17 ADJ PDL 30 Power adjustable pedals
18 CDS 30 Electric cooling fan
