CHASSIS
320
− BRAKES
Pedal clearance
Fixed type
Adjustable type (in frontmost position)
70 mm (2.8 in.) Min. *
1
59 mm (2.3 in.) Min. *
1
Pedal free play
Fixed type
Adjustable type (in frontmost position)
1 − 6 mm (0.04 − 0.24 in.)
1 − 8 mm (0.04 − 0.31 in.)
Brake pad wear limit 1.0 mm (0.04 in.)
Parking brake lining wear limit 1.0 mm (0.04 in.)
Parking brake adjustment 3 − 6 clicks *
2
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
*
1
: Minimum pedal clearance when depressed with the force of 490 N (50 kgf, 110 lbf) with the engine running
*
2
: Parking brake adjustment when depressed with the force of 294 N (30 kgf, 66 lbf)
− STEERING
Wheel free play
Less than 30 mm (1.2 in.)
Power steering fluid type Automatic transmission fluid DEXRON
R
II or III
