KEYS AND DOORS
21
1. Remove the screw, and then the cover while pushing it in the
arrow direction.
2. Remove the module from the key frame.
3. Remove the 2 screws to take out the lid of the module.
4. Take out the discharged battery and put a new battery with
the positive side up.
NOTICE
D Make sure the positive side and negative side of the
battery should be faced correctly.
D Do not replace the battery with wet hands. Water may
cause unexpected rust.
D Do not touch or move any components inside of the
transmitter, or it may interfere with proper operation.
D Be careful not to bend the electrode of the battery
insertion and that dust or oils do not adhere to the
inside of the module.
D Take care not to lose the screws.
