540
ES300h_OM_OM33B71U_(U)
9-1. Specifications
*: The fluid capacity is a reference quantity.
If replacement is necessary, contact your Lexus dealer.
*
1
: Minimum pedal clearance when depressed with a force of 110.2 lbf (490 N, 50.0 kgf)
while the hybrid system is operating.
*
2
: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N, 30.6 kgf).
Hybrid transmission
Fluid capacity* 3.9 qt. (3.7 L, 3.3 Imp.qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■ Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration
in shift quality, locking up of your transmission accompanied by vibration, and ulti-
mately damage the transmission of your vehicle.
Brakes
Pedal clearance*
1
3.54 in. (90 mm) Min.
Pedal free play 0.04 — 0.24 in. (1.0 — 6.0 mm)
Front and rear brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake pedal travel *
2
7  10 clicks
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
Steering
Free play Less than 1.2 in. (30 mm)
