Lexus LFA - Page 296

294
4-3. Do-it-yourself maintenance
13
D-IG1-3 5 A
Electronically controlled brake sys-
tem, VDIM (Vehicle Dynamics Inte-
grated Management)
14
ABS MAIN D2 10 A Electronically controlled brake system
15
ABS MAIN D1 10 A Electronically controlled brake system
16
STOP 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, electronically controlled brake
system, ASG (Automated Sequential
Gearbox), stop/tail lights, high
mounted stoplight
17
DRLCK BAT 25 A Main body ECU
18
HAZ 10 A
Turn signal lights, emergency flashers,
gauges and meters
19
AM2 5 A
IGN, E/G IG, EFI NO.1, EFI NO.2,
ECU-IG2, GAUGE, ASG-IG2
20
PANEL 5 A Interior lights
21
DOME 5 A Interior lights
22
MPX-B 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, main body ECU, rear hatch,
power seat (driver's side), gauges and
meters, VDIM (Vehicle Dynamics
Integrated Management)
Fuse Ampere Circuit
