Lexus LS460 2008 - Page 597

597
4-3. Do-it-yourself maintenance
4
Maintenance and care
19
EDU2 25 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
20
FR CTRL ALT 20 A
Windshield washer, alarm, headlight
cleaner, parking lights, side maker
lights
21
EDU1 25 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
22
RELIEF VLV 10 A Fuel system
23
FR FOG 15 A Front fog lights
24
A/C W/P 10 A
Air conditioning system, electric cool-
ing fans
25
H-LP LVL 10 A
Discharge headlights, headlight high
beams, parking lights, side marker
lights, horns, alarm, windshield washer
26
P-J/ B 10 A P IG2, P RR-IG2
27
INJ 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
28
D/C CUT 2 30 A P MPX-B, RR ECU-B
29
ECU-B 2 5 A Brake system
30
ABS MAIN 3 10 A Brake system, pre-collision seat belt
31
EFI MAIN 2 25 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, exhaust system
32
EFI MAIN 25 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, fuel system
Fuse Ampere Circuit
