596
4-3. Do-it-yourself maintenance
7
E/G RM-IG1-2 10 A
AFS, headlight high beams, parking
lights, side marker lights, horns, alarm,
windshield washer, exhaust system,
headlight cleaner
8
E/G RM-IG1-1 10 A
Charging system, EPS, electric cool-
ing fans, AFS
9
H-LP LL 15 A Headlight low beams
10
ABS MAIN 1 10 A Brake system, pre-collision seat belt
11
H-LP RL 15 A Headlight low beams
12
ETCS 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
13
NV IR 10 A Cruise control system
14
IGN 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, brake system, airbag system
15
ECU-IG 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, stop lights, pre-collision seat belt,
charging system
16
D/C CUT 1 30 A
ECU-B, D MPX-B 1, D MPX-B 2,
P MPX-B, RR MPX-B 1, RR MPX-B 2,
DOME
17
ECU-B 10 A
Headlight high beams, parking lights,
horns, alarm, windshield washer, pre-
collision seat belt, headlight cleaner
18
A/F 15 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, exhaust system
Fuse Ampere Circuit
