Description
1.2 Supplied Equipment
The equipment supplied with the TRIVAC B pump
includes:
Pump with motor, including initial filling of N 62 or HE-
200 oil,
1 centering ring,
1 centering ring with dirt trap,
2 clamping rings DN 40 KF.
For protection during shipment, the connection ports are
each blanked off by rubber diaphragms and supporting
rings.
Switches, motor protection switch, mains cable etc. are
not included.
1.3 Accessories
Cat. No. / Ref. No.
Separator AK 40-65, DN 40 KF . . . . . . . . . . . . . 188 16
Exhaust filter AF 40-65, DN 40 KF . . . . . . . . . . 189 16
Drain tap for condensate trap, exhaust filter
oil drain of the pump,
vacuum-tight . . . . . . . . . . . . . . . . . . . . . . . . . . . 188 91
oil-tight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188 90
Exhaust filter with Iubricant return
AR 40-65, DN 40 KF . . . . . . . . . . . . . . . . . . . . 189 22
Exhaust filter with Iubricant return
ARS 40-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189 57
Dust filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186 15
Fine vacuum adsorption trap (with zeolite) . . . . 187 15
Adsorption trap
(with aluminium oxide) . . . . . . . . . . . . . . . . . . . 854 16
(with cryo insert) . . . . . . . . . . . . . . . . . . . . . . . . 854 19
Oil filter OF 40-65 . . . . . . . . . . . . . . . . . . . . . . . 101 92
Chemical filter CF 40-65 . . . . . . . . . . . . . . . . . . 101 97
Chemical filter with safety cut-off valve
CFS 40-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 77
Adapter for RUVAC 151/251 Roots pumps . . . . 168 30
Adapter for gas ballast port
M 16 x 1.5 – DN 16 KF . . . . . . . . . . . . . . . . . . .168 40
M 16 x 1.5 –
3
/
8
inch NPT . . . . . . . . . . . . .99 175 011*)
Oil N 62 1l 177 01
(order from 5l 177 02
LH Cologne, Germany) 20 l 177 03
Oil HE-200 1 qt 98 198 006
(order from 12 qt case 98 198 049
LHVP, Export Pa., 1 gal 98 198 007
USA) 5 gal 98 198 008
The oil grades N 62 and HE-200 are interchangeable.
*) order from LHVP, Export Pa. USA
1.4 Spare parts
Set of gaskets . . . . . . . . . . . . . . . . . . . . . . . . . 197 21
Pump module, complete S 40 B . . . . . . 200 10 941
D 40 B . . . . . . 200 10 933
S 65 B . . . . . . 200 10 947
D 65 B . . . . . . 200 10 944
Module-gasket . . . . . . . . . . . . . . . . . . . . . 200 10 744*)
Oil case gasket . . . . . . . . . . . . . . . . . . . . 200 10 741*)
Internal demister . . . . . . . . . . . . . . . . . . 390 26 014*)
*) included in gasket set
1.5 Transportation
• Pumps which are filled with operating
agents must only be moved while
standing upright. Otherwise oil may
escape. Avoid any other orientations
during transport.
• Check the pump for the presence of any
oil leaks, since there exists the danger
that someone may slip on spilt oil.
• When lifting the pump you must make
use of the crane eyes provided on the
pump for this purpose; also use the
recommended type of lifting device.
6
Caution
Warning
