Page #12 background imageLoading...
Page #12 background image
Basic Function
By pressing one of the 3 soft buttons you are able to select the indicated function. For instance, if
you want to select call pickup (as shown below), press the first button on the left. If there are more
than three functions available at any point, an arrow will be displayed on the LCD display. Use the
navigation key to move the next or previous screen to display additional functions.
3 Soft Buttons are located below the LCD display.
1. Idle
STATION 700 (T)
FEB 01 04 05:34 pm
PICKUP CONF REDIAL
PICKUP : press to pickup a call ringing within the same pickup
group.
CONF : press to initiate & activate a conference.
REDIAL : press to redial last number called.
1.1 Pickup
A station can pickup a call ringing to an unattended station within the same pickup group by using
the pickup procedure.
Refer to IP LDK system & LDK system programming manual.
STATION 700 (T)
FEB 01 04 05:34 pm
PICKUP CONF REDIAL
Press [PICKUP] button.
CALL TO STA 704
FROM 100 05:37pm
TRANS CONF MUTE
Talk
