4. MOBILE EXTENSION PGM
1
3. SPEED PROGRAM
4. MOBILE EXTENSION PGM
OK
Press [OK] or button.
Press [MENU] button.
Refer to IP LDK system & LDK system programming manual.
4.1 MOBILE EXT. NUM PGM
Press [OK] or button.
1. MOBILE EXT. NUM PGM
2. MOBILE
EXT. ENABLE
BACK OK
> 123456789
MOBILE EXT TEL NO.
BACK OK
Enter the mobile number.
e.g.) 2222222
Press [OK] or button.
> 2222222
MOBILE EXT TEL NO.
BACK OK
4.2 MOBILE EXT ENABLE
Press [OK] or button.
1. MOBILE EXT. NUM PGM
2. MOBILE
EXT. ENABLE
BACK OK
MOBILE EXT. USAGE
> OFF
BACK NEXT OK
Press [OK] or button.
Use [NEXT] or button to toggle ON/OFF.
MOBILE EXT. USAGE
> ON
BACK NEXT OK
