- 7 -
SPECIFICATION
1. Application range
This specification is applied to CL-81 chassis.
2. Requirement for Test
Testing for standard of each part must be followed in below
condition.
(1) Temperature: 25°C ± 2°C
(2) Humidity: 65% ± 10%
(3) Power: Standard input voltage (AC 100-240V, 50/60Hz)
(4) Measurement must be performed after heat-run more than
30min.
(5) Adjusting standard for this chassis is followed a special
standard.
3.General Specification
4. Mechanical Specification
No.
Item
Specification Remark
1
TFT Color LCD Module
15.0 inches(380.16mm) diagonal(Aspect 4:3)
0.297mm(H)x0.297mm(V)xRGB
LVDS
6BIT, 16,777,216 colors
332.8(H) x 262.2(V) x 18(D)
Anti-Glare(HAZE 3%), Hard Coating(3H)
Normally Black
4 CCFL(4 lamps)
R.T.:5ms + F.T.:11ms(Typ)
LPL
NOTE : Specifications and others are subject to change without notice for improvement
.
No.
1 Product Width(W) Lengh(D) Height(H)
Dimension Before Packing 377.6 242.8 394.5
After Packing 433 143 442
2 Product Only SET 5.6Kg
Weight With BOX 7.7Kg
Type
ActiveDisplay Area
Pixel Pitch [mm]
Electrical Interface
Color Depth
Size [mm]
Surface Treatment
Operating Mode
Back light Unit
R/T Typ.
Item Content
Remark
To Next Page
