LG 22LS3700 - Block Diagram

- 22 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
RGB-PC
(JK1104)
Tuner
(TU3704)
Component1 & AV
Component2
(JK1601)
PC-AUDIO
(JK1102)
Main SOC
S7LR(LGE2111A)
(IC101)
SIDE REAR
USB
(JK1450)
HDMI1
(JK801)
HDMI2
(JK802)
(P705)
30P HD LVDS wafer
51P FHD LVDS wafer
(P703)
(P705)
(P703)
TU_SCL / SDA
IF_P/N_MSTAR, TU_CVBS, TU_SIF
SC1/COMP1_L/R_IN
COMP1_Y+/Pb+/Pr+
COMP2_L/R_IN
COMP2_Y+/Pb+/Pr+, AV_CVBS_IN
Ethernet
(JK2100)
SPDIF_OUT
PC_L/R_IN
DSUB_R+/G+/B+, DSUB_H/VSYNC
CK+/-, D0+/-, D1+/-, D2+/-, D3+/-_HDMI2 CK+/-, D0+/-, D1+/-, D2+/-, D3+/-_HDMI1
DDC_SCL/SDA_1 DDC_SCL/SDA_2
HDMI3
(JK803)
CK+/-, D0+/-, D1+/-, D2+/-, D3+/-_HDMI4
DDC_SCL/SDA_4
SIDE_USB_DM/DP
USB1_OCD/CTL
EPHY_RP/N, EPHY_TP/N
OCP IC : AP2191DSG
(IC1450)
+5V_USB1
SPDIF(Optic)
(JK1103)
System EEPROM
(256Kbit)
IC104IC104 IC102
NAND FLASH
(1Gbit)
IC102
IC1201, IC1202
DDR3 SDRAM
(1Gbit)
IC1201, IC1202
Serial Flash
(8Mbit)
IC1401IC1401
SPI_SCK/SDI/SDO/CS
I2C_SCL/SDA
PCM_A[0-7],…
A-MDQL[0-7], A-MDQU[0-7],…
B-MDQL[0-7], B-MDQU[0-7],…
RXA0+/-~RXA4+/-, RXACK+/-
RXB0+/-~RXB4+/-, RXBCK+/-
SPK_R
SPK_L
10P
connector
P2401
10P
connector
P2401
SENSOR_SCL/SDA,
KEY1/2, LED_B, IR
AMP_SCL/SDA
AUD_MASTER_CLK,
AUD_LRCH,
AUD_LRCK, AUD_SCK
NTP-7500L
(IC501)
System EEPROM
BLOCK DIAGRAM
