LG 22LS3700 - Specification

- 6 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This specification is applied to the LCD TV used LB21A
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC : CE, IEC
4. Model General Specification
No. Item Specication Remarks
1. Market
Austrailia, New Zealand, Singapore, Malaysia,
Vietnam, Indonesia,
South Africa, Israel, A-ASIA
only Analog for A-ASIA
2. Broadcasting system
1) PAL/SECAM-B/G/D/K
2) PAL-I/II
3) NTSC-M
4) DVB-T
PAL for NZ/SG
3. Channel Storage ATV - 135EA, DTV - 1000EA
4. Receiving system
Analog : Upper Heterodyne
Digital : COFDM(DVB-T)
▪ DVB-T
- Guard Interval(Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32
- Modulation : Code Rate
QPSK : 1/2, 2/3, 3/4, 5/6, 7/8
16-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
64-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
5. Video(Composite) Input PAL, SECAM, NTSC 4 System : PAL, SECAM, NTSC, PAL60
6. Component Input Y/Cb/Cr, Y/Pb/Pr
7. RGB Input RGB-PC Analog (D-sub 15PIN)
8. HDMI Input
HDMI1-DTV/DVI
HDMI2-DTV/DVI
HDMI3-DTV
PC
- Non 3D HD/FHD Model : HDMI version 1.3
- 3D Model : HDMI version 1.4a
Support HDCP
9. Audio Input RGB/DVI audio, Component, AV
10. SPDIF out SPDIF out
11. USB For My Media(Movie/Photo/Music List) or SVC
12. LAN DLNA Only LB21B
