LG 22MN42A - Page 46

46
ENGLISH
SPECIFICATIONS
24MN42A
LCDPanel ScreenType 598.09mm(23.547inch)TFT(ThinFilmTransistor)
LCDModule.
Visiblediagonalsize:598.0mm
PixelPitch 0.38175(H)x0.38175(V)
VideoSignal Max.Resolution 1366x768@60Hz
RecommendedResolution 1366x768@60Hz
HorizontalFrequency 30kHzto69kHz
VerticalFrequency 56Hzto61Hz
SynchronizationType SeparateSync
InputConnector RF,CVBS,RGB,HDMI,USB(JPEG,MP3)
Power RatedVoltage 19V 2.0A
PowerConsumption OnMode:30W(typ.)
SleepMode1W(RGB)
OffMode 0.5W
AC/DCAdapter Manufacturer:LGInnotek,Model:PSAB-L101A
Manufacturer:Lite-On,Model:PA-1650-64
Dimensions(WidthxHeightxDepth)
Weight
558.6mmx415.1mmx144.9mm
3.8kg
Environmental
conditions
OperatingTemperature
OperatingHumidity
10°Cto35°C
20%to80%
StorageTemperature
StorageHumidity
-10°Cto60°C
5%to90%
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
