LG 22MN42A - Page 47

47
ENGLISH
SPECIFICATIONS
HDMI(DTV)mode
Resolution Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480 31.470 59.940
720x480 31.500 60.000
720x576 31.250 50.000
1280x720 44.960 59.940
1280x720 45.000 60.000
1280x720 37.500 50.000
1920x1080 33.720 59.940
1920x1080 33.750 60.000
1920x1080 28.125 50.000
1920x1080 67.432 59.940
1920x1080 67.500 60.000
1920x1080 56.250 50.000
RGB(PC)supportedmode
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel
clock
(MHz)
640x480 31.469 59.94 25.175
800x600 37.879 60.317 40.0
1024x768 48.363 60.0 65.0
1152x864 54.34 60.05 80
1280x1024 63.981 60.02 108.0
1600x900 55.54 60 97.75
1680x1050 64.674 59.883 119.0
1680x1050 65.290 59.954 146.25
1920x1080 67.5 60 148.5
22MN42A
24MN42A
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel
clock
(MHz)
640x480 31.469 59.94 25.175
800x600 37.879 60.317 40.0
1024x768 48.363 60.0 65.0
1280x720 47.77 59.85 74.5
1152x864 54.34 60.05 80
1280x1024 63.981 60.02 108.0
1366x768 47.71 59.79 85.5
NOTE

Theremaybeinterferencerelatingto
resolution,verticalpattern,contrastor
brightnessinPCmode.ChangethePC
modetoanotherresolutionorchangethe
refreshratetoanotherrateoradjustthe
brightnessandcontrastonthemenuuntilthe
pictureisclear.IftherefreshrateofthePC
graphiccardcannotbechanged,changethe
PCgraphiccardorconsultthemanufacturer
ofthePCgraphiccard.

Thesynchronizationinputwaveformfor
HorizontalandVerticalfrequenciesare
separate.

Connectthesignalcablefromthemonitor
outputportofthePCtotheRGB(PC)portof
theMonitorset

Ifusingasoundcard,adjustPCsoundas
required.

IfthegraphiccardonthePCdoesnotoutput
analogueanddigitalRGBsimultaneously,
connectonlyoneofeitherRGBtodisplay
thePCoutputontheMonitorset.

IfthegraphiccardonthePCdoesoutput
analogueanddigitalRGBsimultaneously,
MonitorsettoeitherRGB.(Theothermode
issettoPlugandPlayautomaticallybythe
Monitorset.)

IfyouuseanRGB-PCcablethatistoolong,
theremaybeinterferenceonthescreen.We
recommendusingunder5mofcable.This
providesthebestpicturequality.
