LG 24MA32D - PC RGB Connection

ENGLISH
27
MAKING CONNECTIONS
(Not Provided)
RGB connection
Transmits analog video from your PC to the TV. Connect the PC and the TV with the D-sub 15 pin cable as
shown the following illustrations. To transmit an audio signal, connect an optional audio cable.
NOTE
If you do not use an optional external speaker, connect the PC to the TV with the optional audio cable.
PC
(Not Provided)
