LG 24MN33D User Manual

ENGLISH
54
EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a crossed (reverse) cable.
Command reference list
(Depending on model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power off k a 00
02. Aspect Ratio k c (See p.56)
03. Screen Mute k d (See p.56)
04. Volume Mute k e 00 to 01
05. Volume Control k f 00 to 64
06. Contrast k g 00 to 64
07. Brightness k h 00 to 64
08. Color/Colour k i 00 to 64
09. Tint k j 00 to 64
10. Sharpness k k 00 to 32
11. OSD Select k l 00 to 01
12. Remote Control Lock Mode k m 00 to 01
13. Balance k t 00 to 64
14. Color (Colour) Temperature x u 00 to 64
15. ISM Method (Only Plasma TV) j p (See p.57)
16. Energy Saving j q 00 to 05
17. Tune Command m a (See p.58)
18. Channel (Programme) Add/Del(Skip) m b 00 to 01
19. Key m c Key Codes
20. Control Back Light, Control Panel Light m g 00 to 64
21. Input select (Main) x b (See p.60)
22. 3D (Only 3D models) x t (See p.60)
23. Extended 3D (Only 3D models) x v (See p.61)
24. Auto Configure j u (See p.61)
* Note: During USB operations such as DivX or EMF, all commands except Power(ka) and Key(mc) are not
executed and treated as NG.

LG 24MN33D Specifications

General

Screen shape	Flat
Response time	9.5 ms
Display diagonal	23.6 \
Display brightness	250 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
LED backlighting type	-
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p
Contrast ratio (dynamic)	5000000:1
Supported graphics resolutions	1280 x 720 (HD 720), 1366 x 768
3D	No
Annual energy consumption	38 kWh
Tuner type	Analog
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	DIVX
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	181 mm
Height (with stand)	418 mm
Weight (with stand)	3900 g
Depth (without stand)	63 mm
Width (without stand)	557 mm
Height (without stand)	343 mm
Weight (without stand)	3600 g
