LG 27UL600-W.AHK Service Manual

SPECIFICATION
NOTE : Specications and others are subject to change without notice for improvement.
1. General Specication
1) 27UL650 / 27BL65U / 27UL600
* * Provided accessory: #8/#9 , it’s different marketing request.
No
Item
Content
Measurement
Result
Remark
1
Customer
BRAND
Checked
BRAND : LGE Product
2
User Model Name
27UL650 / 27BL65U / 27UL600
Checked
1pole stand
3
Sale region
Worldwide
Checked
4
Feature
27 ”LCD MONITOR (ADS UHD HDR)
Checked
ADS =BOE IPS name
5
Chassis Name
LM8CA
Checked
PCB, Product spec., Adjustment spec.
6
General
Scope
External SW & Adj.
Joystick switch
Up / Down / Left / Right / OK
Checked
Press and Hold : Power off
Function
Picture Mode, Ratio, S.E.S, Six Color, On Screen Con
trol,HDR400, Dual Controller, Factory Calibration
Checked
7
Input
HDMI IN
HDMI1(2.0) / HDMI2 (2.0) /HDMI1(1.4) / HDMI2 (1.4)
Checked
DP IN
Display Port(1.4) / Display Port(1.2) / Display Port(1.1)
Checked
Display Port(1.4)  for HDR function
USB-C IN
N/A
N/A
USB DN
N/A
N/A
H/P OUT
Audio L/R
Checked
RS-232C
N/A
N/A
8
Power Cord
Length
1.55±0.05m:
1.55m
Refer to Suffix standard and
power cord Table.
Weight
0.174kg ± 10%,
0.173kg
Color
White
Checked
9
Cable
Phone to RS-232
Length
0.2 ± 0.01m
N/A
Do not provide
Weight
0.02kg ± 10%,
N/A
Color
Black
N/A
USB C To C Cable
Length
1.8 ± 0.03m
N/A
Do not provide
Weight
0.0775kg ± 5%
N/A
Color
White
N/A
Impedance
1) CABLE : 90 Ω±15Ω
2) CONNECTOR : 90 Ω±10Ω
N/A
DisplayPort
Length
1.50m±0.05m
1.5m
P/N : EAD63749403
(Refer to BOM)
Weight
0.136kg ± 10%
0.135kg
Color
White
Checked
Impedance
1) CABLE : 100Ω±5Ω
2) CONNECTOR : 100Ω±10Ω
1) 98.37~101.9ohm
2) 92.33~102.7ohm
HDMI
Length
1.50m ± 0.05m
1.5m
P/N : EAD63954402
(Refer to BOM)
Weight
0.090kg ± 10%
0.090kg
Color
White
Checked
Impedance
1) CABLE : 100Ω±5Ω
2) CONNECTOR : 100Ω±10Ω
1) 96.69~105.73ohm
2) 90.73~108.97ohm
10
Power
(Adapter / PSU /LPB)
Output: DC 19V 2.53A, 48W Adapter
Color: White, Weight : 0.246kg ±10%, with PE bag
Checked
P/N : EAY62933008
(Refer to BOM)
11
Power Rating
Input : DC 19V / 2.4A
Checked
Request to regulation team
12
Accessory Box
-
-
Not applied
13
Applying module list
P/No
Specification
Checked
27” UHD MODULE (BOE)
For KR Suffix : EAJ64428302
EAJ64428301
MV270QUM-N20
