LG 27UP85NP User Manual

6
ENGLISH
Adjusting the Angle
1 Place the monitor mounted on the stand base in an upright position.
2 Adjust the angle of the screen.
The angle of the screen can be adjusted forward or backward from -5° to 15° for a comfortable viewing
experience. (27UP80B)
The angle of the screen can be adjusted forward or backward from -5° to 20° for a comfortable viewing
experience. (27UP850 27BP85U 27UP850N 27BP85UN 27UP85NP)
WARNING
• To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the monitor’s frame as
illustrated below.
• Be careful not to touch or press the screen area when adjusting the angle of the monitor.
27UP850 27BP85U 27UP850N 27BP85UN 27UP85NP
27UP80B
27UP83A
Pivot Feature
27UP850 27BP85U 27UP850N 27BP85UN 27UP85NP
27UP83A
The pivot feature allows the monitor to rotate 90° clockwise.
Head
Stand
WARNING
• To avoid scratching the stand base, make sure that when rotating the monitor using the pivot feature, the
stand does not make contact with the monitor.
1 Raise the monitor to the maximum height.
2 Adjust the angle of the monitor in the direction of the arrow as shown in the figure.

LG 27UP85NP Specifications

General

Color gamut	95 %
Pixel pitch	0.1554 x 0.1554 mm
Screen shape	Flat
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1200:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	68 cm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	3840 x 2160
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	185 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	44 W
AMD FreeSync type	FreeSync
Panel mounting interface	100 x 100 mm
DisplayPort version	1.4
RMS rated power	5 W
Package depth	212 mm
Package width	694 mm
Package height	496 mm
Package weight	8900 g
Cables included	DisplayPort, HDMI, USB Type-C
Product color	Silver
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	239.3 mm
Width (with stand)	613.5 mm
Height (with stand)	569.3 mm
Weight (with stand)	5900 g
Depth (without stand)	45.4 mm
Height (without stand)	363.5 mm
Weight (without stand)	4100 g
