PREPARATION
PREPARATION
20
STAND INSTRUCTIONS (For 19/22LE5300, 22LE5500)
ᯫ
Image shown may differ from your TV.
INSTALLATION
!
NOTE
Ź When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
3
Assemble the TV as shown.
4
Install the 4 screws into the holes shown.
DETACHMENT
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
2
Remove the screws from the TV.
3
Detach the stand from TV.
STAND BASE
STAND BODY
M4 x 14
