PREPARATION
16
PREPARATION
DESKTOP PEDESTAL INSTALLATION
For proper ventilation, allow a clearance of 4 in. on each side and the top, 2.36 in. on the bottom, and 4 in.
from the wall.
4 inches
4 inches
R
4 inches
4 inches
37/42/47/52LB5D
32/37/42LB4D
4 inches
4 inches
4 inches
4 inches
VESA WALL MOUNTING
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
GG
Screw length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE
37/42/47/52LB5D 37/42LB4D
AV IN 2
L/ MONO
R
AUDIO
VIDEO
S-VIDEO
USB IN
AV IN 2
L/ MONO
R
AUDIO
VIDEO
USB IN
400mm
400mm
600mm
600mm
100mm
200mm
32LB4D
