ENGLISH
11
HOW TO JOIN THE SET ASSEMBLY TO THE WALL TO
PROTECT THE SET TUMBLING
or
2
1
■
Set it up close to the wall so the set doesn’t fall over when it is pushed backwards.
■
The instructions shown below is a safer way to set up the set, which is to fix it on the wall so the set
doesn’t fall over when it is pulled in the forward direction. It will prevent the set from falling for-ward and
hurting people. It will also prevent the set from damage caused by fall. Please make sure that children
don’t climb on or hang from the set.
3
Use a sturdy rope (not provided as parts of the set, must purchase separately) to tie the set. It is safer to
tie the rope so it becomes horizontal between the wall and the set.
Use the eye-bolts or TV brackets/bolts to fix the set to the wall as shown in the picture.
(If your set has the bolts in the eye-bolts position before inserting the eye-bolts, loosen the bolts.)
* Insert the eye-bolts or TV brackets/bolts and tighten them securely in the upper holes.
Secure the wall brackets with the bolts (not provided as parts of the set, must purchase separately) on the
wall. Match the height of the bracket that is mounted on the wall.
NOTE
GG
When moving the set to another place undo the ropes first.
GG
Use a set holder or a cabinet that is big and strong enough for the size and weight of the set.
GG
To use the set safely make sure that the height of the bracket that is mounted on the wall is same as
that of the set.
2
3
1
1
3
2
U0585Cen_CD 12/6/06 4:45 PM Page 11
