SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. Module specification(General)
1. Application range
This spec sheet is applied to LCD TV used LP91H chassis.
2. Specification
Each part is tested as below without special appointment.
1) Temperature : 25 ºC ± 5 ºC(77 ºF ± 9 ºF), CST : (40 ± 5) ºC
2) Relative Humidity : 65 % ± 10 %
3) Power Voltage
: Standard input voltage(100 V - 240 V @ 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety: CE, IEC specification
- EMC : CE, IEC
No. Item Specification Measurement Remark
1 Screen Size 32” wide Color Display Module Resolution : 1366*768
2 Aspect Ratio 16:9
3 LCD Module 32” TFT WXGA LCD
4 Operating Environment Temp.: (0 ~ 40) deg
Humidity : 0 % ~ 85 %
5 Storage Environment Temp.: (-20 ~ 60) deg
Humidity : 0 % ~ 85 %
6 Input Voltage AC 100 V - 240 V~, 50/60 Hz
87.5 W HD
7 LCD Module AUO 760 x 450 x 46.9 Outline Dimension
0.51075 x 0.51075 Pixel Pitch
4 CCFLs Backlight assembly
SHARP 760 x 450 x 50 Outline Dimension
0.51075 x 0.51075 Pixel Pitch
8 CCFT Backlight assembly
IPS 697.685 x 392.256 Outline Dimension
0.51075 x 0.51075 Pixel Pitch
4 CCFL Backlight assembly
