PREPARATION
PREPARATION
24
STAND INSTRUCTIONS (For 32/42/47/55LD650, 42/47LD655, 32/37/42/47LD840)
ꔛ
Image shown may differ from your TV.
!
NOTE
► When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
5
(For 32/37/42/47LD840)
Assemble the parts of the STAND REAR
COVER with the TV.
3
Assemble the TV as shown.
4
Install the 4 screws into the holes shown.
A
C
I
N
CAB
L
E
M
A
NA
GEM
E
N
T
AC IN
CABLE MANAGEMENT
AC IN
CABLE MANAGEMENT
STAND BASE
STAND BODY
INSTALLATION
M4 x 20
M4 x 20
