LG 32LD650 - Other A;V Source Setup

45
EXTERNAL EQUIPMENT SETUP
OTHER A/V SOURCE SETUP
1. How to connect
1
Connect the AUDIO/VIDEO jacks
between TV and external equipment.
Match the jack colors
.
(
Video = yellow, Audio Left = white, and
Audio Right = red
)
2. How to use
ꔛ
Select the AV1 or AV2 input source on
the TV using the
INPUT button on the
remote control.
ꔛ
Operate the corresponding external
equipment.
RGB IN (PC)
SS
OL
(RGB/DVI)
/DVI IN
2
3
1
VIDEO
AUDIO
COMPONENT IN
AUDIO IN AUDIO OUT
2
1
VIDEO AUDIO
L(MONO)
R
AV IN 1
YP B P R
L R
OPTICAL DIGITAL
RS-232C IN
( CONTROL&SERVICE)
L R
VIDEO
AUDIO
Camcorder
Video Game Set
