ENGLISH
13
tWhen attaching a wall mounting bracket to the TV, insert the wall
mount spacers into the TV wall mount holes to adjust the vertical
angle of the TV. (Only when the item of the following form is
provided)
Provided Item
Wall Mount Spacer
Connections (notications)
Connect various external devices to the TV and switch input modes to
select an external device. For more information of external device’s
connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio
systems, USB storage devices, PC, gaming devices, and other external
devices.
NOTE
tThis model supports 4K (ULTRA HD) videos only in HDMI input.
(Only UF67**)
tULTRA HD videos are not supported in the tuner or USB input.
(Only UF67**)
tThe external device connection may dier from the model.
tConnect external devices to the TV regardless of the order of the
TV port.
tIf you record a TV program on a DVD recorder or VCR, make sure to
connect the TV signal input cable to the TV through a DVD recorder
or VCR. For more information of recording, refer to the manual
provided with the connected device.
tRefer to the external equipment’s manual for operating
instructions.
tIf you connect a gaming device to the TV, use the cable supplied
with the gaming device.
tIn PC mode, there may be noise associated with the resolution,
vertical pattern, contrast or brightness. If noise is present, change
the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE
menu until the picture is clear.
tIn PC mode, some resolution settings may not work properly
depending on the graphics card.
tIf ULTRA HD content is played on your PC, video or audio may
become disrupted intermittently depending on your PC’s
performance. (Only UF67**)
Antenna connection
Connect the TV to a wall antenna socket with an RF cable (75 Ω).
tUse a signal splitter to use more than 2 TVs.
tIf the image quality is poor, install a signal amplier properly to
improve the image quality.
tIf the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.
tAn antenna cable and converter are not supplied.
tSupported DTV Audio: MPEG, Dolby Digital, Dolby Digital Plus,
HE-AAC
Adapter connection
(Depending on model)
CAUTION
tPlease be sure to connect the TV to the AC-DC power adapter
before connecting the TV’s power plug to a wall power outlet.
Satellite dish connection
(Only satellite models)
Connect the TV to a satellite dish to a satellite socket with a satellite RF
cable (75 Ω).
HDMI ULTRA HD deep colour
settings
(Only UF67**)
tSETTINGS
PICTURE HDMI ULTRA HD Deep Colour
HDMI (1/2) ULTRA HD Deep Colour
- On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0)
- Off : Support 4K @ 50/60 Hz (4:2:0)
tAll HDMI ports support the HDCP 2.2.
t4K Source is only supported in HDMI input.
t4K signal and content are not available in the RF/USB input.
tAll HDMI input ports support 4K @ 50/60 Hz (For details on the
supported specications, refer to the table below.) for high-
denition video. Picture or sound may not be supported depending
on the specications of the external device connected. In that case,
change the settings for
HDMI ULTRA HD Deep Colour.
