LG 32LF550U-ZA User Manual

- 20 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4. EU T/C 2D Model
Main SOC
M1A-LGE2134
(IC101, DDR3 256MB)
(P1801)
30P HD LVDS wafer
51P FHD LVDS wafer
(P1800)
COMP2_Y+/Pb+/Pr+/L_R_IN or AV_CVBS_IN/L_R_IN
CK+/-, D0+/-, D1+/-, D2+/-_HDMI2
DDC_SCL/SDA_2, HDMI_CEC
Serial Flash
(IC1300, 8Mbit)
SPI_SCK/SDI/SDO/CS
System EEPROM
(IC104, 256Kbit)
I2C_SCL/SDA
RXA0+/-~RXA4+/-, RXACK+/ -
RXB0+/-~RXB4+/-, RXBCK+/ -
SPK_R
SPK_L
AMP_SCL/SDA
AUD_MASTER_CLK,
AUD_LRCH,
AUD_LRCK, AUD_SCK
TAS5733
(IC5600)
Connector
(P4600)
HDMI1
(JK4200)
F-SCART
(JK2801)
SPDIF_OUT
SPDIF(Optic)
(JK1001)
except LF54
USB
(JK700)
HDMI2
(JK4201)
CK+/-, D0+/-, D1+/-, D2+/-,_HDMI4
DM/DP
USB1_OCP/CTL
SN1406035RGER
+5V_USB
HP_L/ROUT
Headphone
(JK3000)
Only LF62/57/56
NAND FLASH
IC102 (1Gbit)
H27U1G8F2CTR -BC
PCM_A[0:7]
T4LCX244FT Buffer
TS_DATA[0:7]
PCM_DATA[0:7]
COMPONENT
(JK2802)
PCM_A[8:14]
X-tal
24MHZ
SC1/AV2_CVBS_IN, SC1_R+/G+/B+
DTV/MNT_OUT, DTV/MNT_L/R_OUT
TU_SCL / SDA
Tuner
(TU2600)
H/NIM
IF_N/P
IF_AGC
FE_TS_DATA[0:7]
CI SLOT
(P1900)
OCP
DDC_SCL/SDA_4, HDMI_CEC
REAR
SIDE
Jog KEY, LED_R, IR

LG 32LF550U-ZA Specifications

General

Screen Size	32 inches
Display Type	LED
Resolution	1366 x 768
Refresh Rate	50 Hz
HDMI Ports	2
USB Ports	1
Smart TV	No
Built-in Wi-Fi	No
Energy Rating	A+
Audio Output	10 W
Digital TV Standard	DVB-T2
