Trouble shooting guide
6. RGB Video
Check input signal format.
Is it supported?
Check RGB Cable conductors
for damage or open conductor
Check EDID & EEPROM
IC1105 I2C Signal
R1141, R1143(SDA,SCL)
Check JK1104
H/V_Sync/R/G/B Signal Line
-R4024/4025/C204/206/208/210
ok
ok
ok
No
No
Replace the defective IC or re-download EDID data
ok
Replace Jack
Check DSUB_DET
Replace R1146 or R1147
No
Check Mstar LVDS Output
Replace Mstar(IC100) or Main Board.
ok
No
